Morimoto BigBanger HXB LED Pod (Combo / White / Each)

Morimoto BigBanger HXB LED Pod (Combo / White / Each), part number BAF124, from Morimoto.

Specifications

• Intensity: 230,700 Cd (Post Warm-Up) (2,307 lux @ 10m)
• Input Voltage: 9-18V DC
• Input: Integrated Deutsch DT 4-Pin
• Power (Stabilized): 77.0w, 30w (Backlight), 8w (Dim Backlight)
• Current (@ 13.5V DC): 5.55A (Stabilized), 8.15A (Startup), 2.2A (Backlight), 600mA (Dim Backlight)
• Peak Luminosity (lm)(raw): 7,000lm
• Dimensions: 154mm W, 136.7mm H (153.5mm w/ Bracket), 76.1mm D
• Light Source: 7x Osram HX Boost (5700K), 12x CREE XP-E2 PC Amber (Backlight)
• Material: Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum (Housing)
• IP RATING: IP69K (Dust / High Pressure Water Resistant)

In the box

• LED Pod: 1x Morimoto BigBanger HXB Combo (White) (Sold Each)
• Bracket: 1x Universal Bottom Mount U Bracket
• Hardware: Complete pack (stainless steel)

Compatibility, as listed by Morimoto

• Universal: With Included U Brackets
